HF Bands
(WARC incl.) |
RX/TX 1
RX./TX 2
PA 1
Antenna |
YAESU FT-2000 (100W) + IF2000 + SDR-IQ
YAESU FT-1000MP (IF2 & 3 filters full set)
HL-1KFx (MOS-FET, 500 W output,
"Tokyo HY-Power")
160m: - Inv-L;
80m: - Inv-V;
40-10m (incl. WARC): - R-8 (vert.
"Cushcraft") |
| 50 MHz |
RX/TX
PA
Antenna |
KENWOOD TS-2000, YAESU FT-2000
GS-31B (>500 W) Home build
5 el. (Värgarda) |
| 70 MHz |
RX/TX
PA
Antenna |
FT-847 (modified), 70 W output
GS31B (400W), Home build
7 el. yagi (ef-4070A) by YU7EF |
| 144 MHz |
RX/TX
RX/TX 2
Preamp
PA 1
PA 2
Antenna |
Kenwood TS-2000, YAESU FT-847 and FT-736R
Transverter XV144 (Elecraft) + FT-1000MP (IF 28 MHz)
MVV-144 (3SK121 from "SHF-Elektronik", 0.4 db)
Mirage B-5030-G (250 W). Using as a driver for PA2.
GS35B (> 1KW output) Home build
4 x 2M18XXX. Limited elevation (45 degrees) |
| 432 MHz |
RX/TX
RX/TX2
Preamp
PA
Antenna
|
Kenwood TS-2000, YAESU FT847, FT-736R
Ttansverter XV432 (Elecraft) + FT-1000MP (IF 28 MHz)
MVV-432 (3SK121 from "SHF-Elektronik", 0.7 db)
HL-250 Udx (250 W, "Tokyo HY-Power")
8 x 19 el. (Värgarda) , Full elevation
|
| 1296 MHz |
RX/TX 1
RX/TX2
Preamp
PA
Antenna 1 |
FT-1000MP +
X-verter
1296/28 (Down East Microwave Inc.),
YAESU-736R
MVV-1296 (SHF-Elektronik, 1.1 db)
I am not satisfied of that!
70 W Transistors. Home build
4 x 23CM35EZ (M2)
|
| Coaxial Cables |
144 Mhz TX
144 Mhz RX
432 Mhz TX
432 Mhz RX
1296 Mhz |
LDF4-50 HELIAX. 23 m long;
8D-FB. 23 m long
LDF4-50 HELIAX. 16 m long;
H-2000 Flex. 16 m long
TX/RX: H-2000 Flex. 18 m. long |
Satellites
(temporary not active) |
RX/TX
Antennas
and preamp.
Antenna 2 |
FT847 + DB6NT down converter (2401/145 MHz)
145 Mhz: 2x 9 el. cross-yagi. Preamp. IC-25 on the mast;
435 Mhz: 2x19 el. cross-yagi Preamp. IC-35 on the mast;
Antennas mounted on dielectric boom with full elevation.
60 cm dish with 12m of H100 cable (dismounted now) |
| 0.01-30.0 MHz |
SDR receiver |
SDR-IQ From RFSPASE, Inc. Using as a panoramic
indicator for 2-nd IF of FT-736 (13.69 mhz) and panadater for
FT1000MP, when using together with VHF/UHF/SHF transverters. |
| Meteor scatter |
DTR |
Digital tape recorder by DF7KF for HSCW MS;
MS-Soft by OH5IY, version 5.1
For meteor showers prediction, geometry, sked manager and TX keying. |
APRS
(HF, VHF) |
Mobile
Base |
KENWOOD TH-D7A(G2) HT Transceiver
YAESU FT-817 + AGW (Sound card) |
| QRP |
RX/TX
Antenna |
YAESU FT-817 1.8 - 435 Mhz All mode. (5 W max.)
ATAS-100 (Car mounted), magnetic loop and different wires |
| Rotators and Controllers
|
. |
3 x YAESU G-1000SDX (Azimuth), YAESU G-500A (Elevation
432Mhz), home build for 144 Mhz.
KCT (Azimuth and elevation for satellite antennas).
EA4TX
ARSWin, (Azimuth and elevation of antennas). Running under
F1EHN's "EME System" program. |
| Software |
Contests HF
Contest VHF
DX4WIN
VQLog
DX Atlas
Sat Tracking
MS and EME
RX/TX CAT &Doppler correction |
N1MM Logger by Tom, N1MM.
Free program
VHF Logger
ver.1.21 by Ulf, SM0LCB. Free program
Version 8.05. My main electronic log for HF and common log.
Ver 3.1B by Gabriel, EA6VQ. My main electronic log for VHF
Version 2.25 by VE3NEA
Nova for
Windows32. DemoVersion 2.2b
WSJT version 7.0 r.996 (JT6M), ver. 9.02
(some new modes)
Ham Radio Deluxe ver. 5.0 by Simon Brown, HB9DRV
|
